The ATZ3600EU is a robust, high-capacity portable power station engineered to deliver reliable and versatile power for a wide range of AC and DC devices. With a remarkable 2048 Wh capacity and a 3600W inverter (peaking at 5400W with pure sine wave output), the ATZ3600EU is capable of powering nearly any device, making it ideal for outdoor adventures, emergency backup, and remote work setups.
Equipped with the ability to power up to 14 devices simultaneously, this power station offers a comprehensive selection of AC, DC, and USB connections to meet diverse power requirements. This makes it suitable for everything from high-energy appliances and essential home devices to portable electronics. With its combination of high-capacity storage, powerful output, and multi-device compatibility, the ATZ3600EU is an essential tool for anyone seeking dependable power in any situation.
The ATZ3600EU power station is designed for a broad range of applications, offering versatility and expandability to meet diverse power needs. It is ideal for recreational and outdoor uses, including RVs, camping, outdoor work, and aerial photography. As a reliable indoor power source, it provides essential backup during power outages, making it suitable for both home and small office settings. Built with a durable lithium iron phosphate (LiFePO4) battery, it ensures long cycle life, stability, and safety. Additionally, the ATZ3600EU supports capacity expansion with an optional secondary battery pack with 2048Wh, allowing users to customize and increase power storage as needed.
Special Features
- Rated AC output power: 1000W
- Rated Capacity: 2048Wh
- Versatile Applications: RV camping, Aerial photography, Outdoor operations, Home backup power, etc.
- Multiple Charging Methods: Solar, Diesel generator
- Superfast Charging: Fully charged in 2.1 hours(1)
- Durable: Energy storage lithium battery core with BMS management, over 3000 cycles(2)
(1) Main battery pack fully charges in 2.1 hours with AC and maximum PV charging (1000W Power, 20A)
(2) DOD 70% (discharge at 0.5C, charge at 1C) at 25°C.
Technical Specifications
| Manufacturer model |
ATZ3600-BATT |
| EAN Code |
4260558576396 |
| Article Number |
7203600-EPEVER |
| Battery type |
Lithium iron phosphate |
| Rated voltage |
51.2VDC |
| Range of operating voltage |
40.0VDC ~ 58.4VDC |
| Range of operating temperature |
Discharging: -20°C ~ 50°C; Charging: 0°C ~ 50°C |
| Nominal capacity |
2048Wh |
| Rated discharging power |
1000W |
| AC charging time |
2.1 hours |
| AC charging power |
1000W |
| Max. MPPT input power |
1000W |
| MPPT voltage range |
11VDC ~ 60VDC |
| Max. PV charging current |
20A |
| Charging environment temperature |
0°C ~ 40°C |
| Discharging environment temperature |
-20°C ~ 40°C |
| Recommended working environment temperature |
20°C ~ 35°C |
| Storage environment temperature |
1 month: -10°C ~ 50°C; 3 months: -10°C ~ 45°C; 6 months: -10°C ~ 30°C |
| Relative humidity |
< 80% |
| Altitude |
< 4000 meters (derating is required for operation at greater than 2000m) |
| Protection degree |
IP20 |
| External dimensions(L x W x H) |
498 x 196 x 224.4 mm |
| Net weight |
15.5kg |
